The improved cutting action means less pressure on the mix and improved feed ration for your animals.

Jaylor Single Auger mixers are available in a variety of configurations ranging in capacity from 9.9 to 16.3 cubic metres. Ideal for feeding small to mid-sized dairy and cow-calf operations, medium-sized beef feedlots (especially backgrounding and grower operations), as well as large sheep and goat facilities. Each Jaylor is a class leader in quickly processing round or square baled hay and/or baleage into uniform rations that will resist sorting. All Jaylor 5000 Series mixers come standard with Jaylor’s 19mm patented square cut auger.

Features

• Ladder and Platform
• Mixer Level
• Shaker Box
• Square Cut Auger with Sloped Top
• Slide Plate Technology
• Tungsten Carbide Coated Knives
• Welded Mixing Chamber
• Mix Viewing Window
• 2 Restrictor Blades
• Structurally Reinforced Frame

• Rapid Discharge Door
• Galvanized 6’ 41” Discharge Conveyor
• Adjustable Cast Towing Ball Hitch
• Heavy Duty Hubs
• Heavy Duty Single Straight Axle
• 3 Point Weigh System
• Heavy Duty Planetary Gearbox
• Patented Open Loop Oil Reservoir
• Shear Bolt Protection
• Wheel Assembly - Single Straight Axel

Get Finance

View Specs

Product Video

DOWNLOAD BROCHURES

2018 Jaylor Single Auger

TALK TO A SALESPERSON

First Name*

This field is required

Last Name*

This field is required

Phone Number*

This field is required Not a valid number!

Email Address*

This field is required This is not a valid email.

Questions/Comments

reCAPTCHA is required

For more information on how we collect, hold, use and disclose personal information, please see our privacy policy.

Single Auger GALLERY

Click on the images below to enlarge.

Model Specifications

Model	Capacity	Min. HP (PTO)	PTO Speed	Standard Knives per Auger	Standard Extension
Jaylor 5350	12 cubic metres	60hp	540	9	16"
Jaylor 5425	15.3 cubic metres	70hp	540	9	16"
Jaylor 5575	16.3 cubic metres	80hp	540	11	16"

Jaylor founder, Jake Tamminga, began designing and manufacturing innovative Vertical TMR (Total Mix Ration) feed mixers for dairy and beef farmers in 1993. Jaylor mixers were soon distributed throughout North America and 50 countries world-wide. In Australia, Jaylor Feed Mixers are exclusivley distributed by PFG Australia Pty Ltd Today, Jaylor is a successful international corporation, but its never forgotten where it started and still maintains its roots firmly planted on the farm, with its production facilities located in rural Orton, Ontario. JayLor is distributed by PFG Australia based in Melbourne, Victoria.
